2020 E-Z-GO RXV® ELiTE

MANUFACTURER INFO

• System Type: 56-Volt AC
• Motor Output: 4.4 hp (3.3 kW) continuous
• Controller: 235 Amp AC Controller
• Top Speed: 17.5–19.5 mph (28–31 kph)

Battery & Charger

• Battery: Dual 56V Lithium ELiTE batteries
• Charger: 56VDC Lithium World Charger (available with 11 ft. or 18 ft. cord)

Drivetrain

• Drive Type: Motor shaft direct drive
• Transmission: Limited slip differential
• Gear Selection: Integrated Forward–Neutral–Reverse
• Rear Axle Ratio: 16.99:1
• Steering: Double-ended rack and pinion

Chassis & Frame

• Body Material: Injection-molded TPO
• Frame: Welded steel with powder-coat protection

Suspension

• Front: Independent A-arm with coil-over shocks
• Rear: Mono-leaf springs with hydraulic shocks

Brakes

• Service Brake: Induction motor braking system
• Parking Brake: Automatic electromagnetic

Wheels & Tires

• Front Track Width: 35.5 in (90 cm)
• Rear Track Width: 38 in (97 cm)
• Front Tire: Turf 18 x 8.50-8 (4-ply rated)
• Rear Tire: Turf 18 x 8.50-8 (4-ply rated)

Dimensions

• Overall Length: 94.5 in (240 cm)
• Overall Width: 47.0 in (119 cm)
• Overall Height:
  • Without roof: 47.5 in (121 cm)
  • With roof: 70 in (178 cm)
• Wheelbase: 65.7 in (167 cm)
• Ground Clearance: 4 in (10 cm)
• Outside Clearance Circle: 19.2 ft (5.8 m)

Capacities

• Seating: 2 passengers
• Cargo Capacity: 800 lb (360 kg)
• Towing Capacity: Up to three E-Z-GO golf cars (with approved tow bars)

Weight

• Without Batteries: 605 lb (274.4 kg)
• Curb Weight: 655 lb (297.1 kg)

Electrical

• System Voltage: 56-Volt

Available Colors

Almond, Black, Bright White, Burgundy, Electric Blue, Flame Red, Inferno Red, Ivory, Metallic Charcoal, Oasis Green, Ocean Grey, Patriot Blue, Sunburst Orange
